| Throughput | 130 Seconds/Test |
| Test Range | 3% - 20% |
| Sample Volume | 10 μL |
| Sample Loader | 5 Position/Rack |
| Reagents |
Eluent A Eluent B Haemolytic Reagent L |
| Certification | NGSP/IFCC certified for HbA1c testing accuracy. |
| Column and Filter Life | Column life of over 1200 tests; filter life of over 600 tests. |
| Reagent Capacity | 150 Tests / Kit |
| Printing | Built-in thermal printer. |
| Operating System | Linux with self-diagnostic capabilities. |
| Display | Large 10.1” TFT True Colour LCD Touch Panel. |
| Dimensions | 450 mm (L) × 360 mm (W) × 540 mm (H) |
| Weight | 32.8 kg |
| HbA1a, HbA1b HbF, LA1c, HbA1c, HbA0, and V-Window(HbE, HbD, HbS, HbC) |
