BC200

BC200

The BC 200 is a state-of-the-art fully automated clinical chemistry analyzer designed to deliver exceptional performance, reliability, and operational efficiency for modern diagnostic laboratories. With a throughput of up to 200 tests per hour, the analyzer enables laboratories to manage routine as well as high-volume workloads while maintaining rapid turnaround times and uncompromised analytical quality.

Designed to meet the evolving needs of laboratories of all sizes, the BC 200 features 40 refrigerated reagent positions and 40 sample positions, providing the flexibility to run a comprehensive test menu without frequent reagent replacement. The integrated barcode scanner ensures accurate sample identification and effortless connectivity with Laboratory Information Systems (LIS) and Hospital Information Systems (HIS), minimizing manual intervention, reducing transcription errors, and streamlining laboratory workflow.

The analyzer is equipped with 44 high-quality reusable reaction cuvettes supported by an advanced on-board automatic washing system. This intelligent washing mechanism effectively minimizes carryover, enhances analytical precision, and extends the lifespan of the cuvettes, resulting in lower operating costs while ensuring consistently reliable test results.

Engineered for versatility, the BC 200 performs a wide range of clinical chemistry and immunoturbidimetric assays with outstanding accuracy and reproducibility. Its precision dispensing system, advanced optical technology, and intelligent software enable laboratories to deliver dependable results across routine biochemistry panels, protein assays, and specialized immunoturbidimetric parameters.

The user-friendly software interface, intuitive workflow, and automated maintenance functions simplify day-to-day laboratory operations, allowing technicians to focus on patient care rather than instrument management. Built-in quality control features, automatic calibration management, and comprehensive data handling capabilities further enhance operational confidence and laboratory efficiency.

To ensure uninterrupted laboratory performance, the BC 200 is integrated with Matrix’s proprietary proactive Customer Relationship Management (CRM) platform. This intelligent remote monitoring solution continuously tracks instrument health and performance, enabling predictive maintenance and early detection of potential issues before they impact laboratory operations. Supported by the highly experienced MX Care service team, customers benefit from rapid technical assistance, proactive service interventions, and minimal instrument downtime, ensuring maximum productivity and peace of mind.

Specification

BC-200: Fully Automated Biochemistry Analyzer
General Information
Machine TypeRandom access, closed system
Test SpeedUp to 200 tests/hour
Test PrincipleColorimetric method and turbidimetry
Test Method1-point end, 2-point end, fixed-time and kinetic
Calibration TypeLinear and nonlinear
Mixing System
MixerPaddle-type mixing, effectively reducing carry-over
Sample Unit
Sample Tray40 sample positions
Sample TubeMicro cups, test tubes and blood collection tubes can be used. Diameter: 12–13 mm; height: 25–100 mm
Sample Volume2–30 µL, adjustable in 0.1 µL steps
Sample BarcodeInbuilt sample barcode reader
Reagent Unit
Reagent Tray40 reagent positions with a non-stop Peltier cooling system; 24-hour refrigeration at 2–14 °C
Reagent Volume20–300 µL, adjustable in 1 µL steps
Reagent NeedleLiquid-surface detection, real-time liquid-volume tracking and collision avoidance
Reagent BarcodeInbuilt reagent barcode reader
Optical System
Light SourceHalogen lamp
Wavelengths340 nm, 405 nm, 450 nm, 505 nm, 546 nm, 578 nm, 630 nm and 700 nm
Absorbance Range0–4.0 Abs
Resolution0.0001 Abs
Operating System
Operating SystemWindows XP, Windows 7, Windows 8 and Windows 10
Data ProcessingAutomatic calibration; test combination; effective reagent-time management; serum index; whole-process detection; linear expansion of enzymes; blank deduction; dirty-cuvette memory; cross-contamination prevention; patient-information memory and association input; automatic report auditing; fuzzy data query; report statistics and printing; reference-range grading; alarm-information classification; and user-privilege management.
Report PrintingSix optional formats with support for customised report patterns
InterfaceTCP/IP network interface
Working Conditions
Power SupplyAC 110/220 V ±10%, 50/60 Hz, 650 W
Water ConsumptionMaximum 6 L/hour
Dimensions (L × W × H)750 × 535 × 475 mm
Weight80 kg

Assay Menu - 120+

BIOCHEMISTRY TEST MENU
🩺 Extended Renal Profile
  • Calcium
  • Cystatin C
  • Magnesium
  • Microalbumin
  • Complement C3
  • Complement C4
🌡️ Inflammatory Profile
  • ASO
  • C-Reactive Protein
🩸 Diabetic Profile
  • Glucose
❤️ Cardiac Profile
  • Creatine Kinase-NAC
🧬 Lipid Profile
  • Triglycerides
  • HDL Cholesterol
  • LDL Cholesterol
  • Total Cholesterol
🔬 Extended Lipid Profile
  • Lipoprotein (a)
  • Apolipoprotein B
  • Apolipoprotein A1
🧪 Pancreatic Profile
  • Amylase Kit
🦴 Arthritis Profile
  • Rheumatoid Arthritis
🫀 Liver Function Profile
  • LDH
  • GOT (AST)
  • GPT (ALT)
  • Albumin
  • Gamma GT
  • Total Protein
  • Bilirubin Total
  • Bilirubin Direct
  • Alkaline Phosphatase (ALP)
⚗️ Other Parameters
  • Zinc
  • Lactate
  • Ammonia
  • Bicarbonate
  • Cholinesterase
🧲 Iron Profile
  • Iron
  • TIBC
  • Ferritin
  • Transferrin
💧 Renal Profile
  • Urea
  • Uric Acid
  • Creatinine
  • Phosphorus
